Panerai

Luminor Submersible 47 3 Days Chrono Flyback Navy Seals Experience Edition

REF. PAM01402

Case

MaterialTitanium, Ceramic
Diameter47 mm
Lug width26 mm
ShapeCushion
CrystalSapphire
Case backNavy Seals Experience Edition
Water resistance300 m

Dial

ColourBlack
FinishMatte
IndexesStick / Dot Hands: Sword
HandsSword

Movement

CaliberP.9100/R
Typeautomatic
Reserve72 h
Explore caliber→

In Context

At 47 mm this is exceptionally large for something worn on a wrist, closer to a pocket watch given lugs. The sapphire crystal will resist everything short of deliberate abuse. 300 m is a professional diving rating, far past any demand a wrist is likely to make of it.

The movement winds itself from the motion of your wrist. 72 hours of reserve puts it well past a weekend — several days off the wrist and it is still going. At 28,800 vph the seconds hand advances 8 times a second.

PAM01402 stands on its own in this catalogue — no other reference here shares its base number. It pairs a black matte dial with a titanium, ceramic case. It was a limited edition.

Inside: Caliber P.9100/R

Explore this caliber →

Regatta version of cal. 9100. The P.9100/R calibre is a development of the P.9100 automatic calibre with chronograph function. With its flyback chronograph with vertical clutch and column wheel, the P.9100/R is identical in architecture and diameter (13¾ lignes) to the P.9100 but it is a little thicker (9.55mm) and it has 26 more parts (328 altogether) as a result of the greater constructional complexity resulting from the addition of the Regatta countdown function. The indication of the countdown to the start is displayed by the two central hands, and it is controlled by the push-button at four o’clock. The minute hand moves backwards by one minute each time the push-button is pressed, until it reaches the position required for the duration of the countdown. At this point it is only necessary to press on the push-button at ten o’clock to start the chronograph function. The hands begin to move, indicating the minutes and seconds which remain before the start, and when the countdown is completed, they continue to measure the time, thus displaying the time elapsed since the start of the race until the chronograph is stopped. The device which enables the minute hand to be moved backwards when the countdown function is operated is controlled, like the whole chronograph, by the column wheel. This is taller than the one in the P.9100 calibre so that it can engage the correcting lever which is mounted higher up, being located on an additional plate.

11 other watches in the library run the Panerai P.9100/R.
